Steel Scrap Grapple

Hydraulic grapples are designed for loading and unloading materials,such as woods,logs,timbers, sugarcane, wood, stone, steel slag, haystack,scrap metal and other special operations. Quality Excavator Rock Stone Log Timber Tree Wood Rake Grapple for Excavator Log Grab Steel Scrap Wood Rock Stone Hydraulic Rotating Orange Peel Grapple

Double Cylinder

Item/model	Unit	DN-04	DN-05	DN-06	DN-08
Weight	Kg	380	430	730	1280
Max jaw opening	Mm	1500	1500	2000	2200
Oil pressure	Kg/cm’	120-160	120-160	150-170	160-180
Set up pressure	Kg/cm’	180	180	190	200
Operating flux	Lmin	50-100	50-100	90-110	100-140
Cylinder Volume	Litre	4.5×2	4.5×2	8.0×2	9.7×2
Suitable excavator	Ton	5-10	12-18	12-18	18-30

Single Cylinder

ltem/model	Unit	DN-04	DN-05	DN-06	DN-08
Weight	kg	380	410	700	1100
Max jaw opening	mm	1250	1250	1700	2000
Oil pressure	ber	120-160	120-160	150-170	160-180
Set up pressure	bar	120	120	120	120
Operating flux	lpm	50-100	50-100	90-110	100-140
Cylinder Volume	litre	8.0×1	8.0×1	8.0×1	9.7×1
Suitable excavator	Ton	5-10	12-18	12-18	18-30

Quality Excavator Rock Stone Log Timber Tree Wood Rake Grapple for Excavator Log Grab Steel Scrap Wood Rock Stone Hydraulic Rotating Orange Peel Grapple

Main Features:
1.Unlimited clockwise and anti-clockwise 360° rotary swing bearing system 3+2, 4+3, 5+4 fingers for your option.
2.Pin and bush heat-treated, increase strength and wear-resistance.
3.Brake valve make it safer from inertia or accident.
4.Welders with ten years of experience, the welding process removes the hard force, and there will be no welding cracks for our hydraulic steel grapple.
